Laser OpticsStandard products
平凸反射镜基片/反射镜基片[TOP]指标：
材料：UV级熔石英
直径公差：+0.0/-0.15mm
厚度公差：±0.2mm
有效孔径：大于80%
面形不规则度：小于λ/8 @632.8nm
表面质量：20-10
保护性倒角Part No. R(mm) φ(mm) tc (mm) ALPX1101 8 8 3 ALPX1102 11 8 3 ALPX1103 15 8 3
平凹反射镜基片/输出耦合镜基片[TOP]指标：
材料：UV级熔石英
直径公差：+0.0/-0.15mm
厚度公差：±0.2mm
有效孔径：大于80%
面形不规则度：小于λ/8 @632.8nm
表面质量：20-10
保护性倒角Part No. R(mm) φ(mm) Te (mm) ALPV1101 -3 6 3.8 ALPV1102 -50 6 3 ALPV1201 -10 10 3 ALPV1202 -20 10 3 ALPV1203 -25 10 3 ALPV1204 -30 10 3 ALPV1205 -35 10 3 ALPV1206 -40 10 3 ALPV1207 -50 10 3 ALPV1208 -75 10 3 ALPV1209 -100 10 3 ALPV1210 -150 10 3 ALPV1211 -400 10 3
