- Wedge Prisms
Wedge prism is an optical element with surfaces inclined toward each other at a very small angle. It diverts light toward the thicker area. Wedge prisms can be used as isolating components as well as to produce a small deviation which doesn't allow return to source.
By selecting the appropriate wedge it is simple to create a precise beam deviation without affecting other beam parameters. If two wedges are used together with the sloping surfaces in close proximity it is possible to produce a continuous variation of beam deviation by counter-rotating the wedges.
Specifications:
Material: BK7 grade A optical glass
Design Wavelength: 632.8nm
Design Index: 1.51467 @632.8nm
Diametre Tolerance: +0.0, -0.15mm
Thinkness Tolerance: +/-0.2mm
Clear Aperture: >85% of diametre
Surface Quality: 60-40 scratch and dig
Flatness: λ/4 @632.8nm
Wedge Angle: <1 arc minute
Bevel: 0.25mmx45deg
